Conductor with a wire wound round a coil

inductor formed with wire wound round a ferrite cylinder, an inductor is a passive dual terminal electrical component designed to oppose changes in electric current.

Image 26 of 95

Image Description

inductor formed with wire wound round a ferrite cylinder, an inductor is a passive dual terminal electrical component designed to oppose changes in electric current.

Keywords: change conductor copper current electrical electromagnetic oppose wire wound circuit component wiring electricity coil terminal EMF back emf filter
Resolution:: 3500 x 2329
File size:: 897 kB
